TelaioCarbon HMFIntegrated Suspension TechnologyVirtual 4 Link kinematic / Adjustable head angleSyncros Cable Integration SystemTQ HPR50 / UDH Interface / 12x148mm with 55mm ChainlineRange Extender Ready
EscursioneFront: 160mm / Rear: 155mm
ForcellaFOX 36 Float Factory Air / Kashima FIT43 modes with low Speed adj. / Kabolt 15x110mm axle44mm offset / tapered steerer / Reb. Adj. / Lockout160mm travel
Ammortizzatore posterioreFOX NUDE 6T Factory EVOL TrunnionSCOTT custom w. travel / geo adj.3 modes: Lockout-Traction Control-DescendLow Speed Adj. / Custom large Air volume / Kashima / Reb. Adj.Travel 155-100-Lockout / T185X55mm
comando remotoSCOTT TwinLoc 2 TechnologySuspension & Dropper Remote3 Suspension modes
MotoreTQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
BatteriaTQ Internal 360Wh + Range Extender 160Wh
SchermoTQ HPRBluetooth / ANT+ / Dedicated Smartphone app
CaricatoreTQ 100-240V-4A
Deragliatore posterioreSRAM XX Eagle AXS Transmission 12 SpeedWireless Electronic Shift System
Leve del cambioSRAM AXS Pod Ultimate Controller
GuarnituraFSA Carbon crankset / 175mm / 34T
Guidacatenae*thirteen / e*spec Slider
CoronaScott custom spider / SRAM Eagle Transmission 34T chainring
CatenaSRAM CN XX Eagle Transmission
Cassetta SRAM XX Eagle XS 1297 Transmission 10-52
FreniSRAM Code Ultimate Stealth 4-Piston Disc
Disco del frenoSRAM HS2 Rotors F&R 200mm
ManubrioSyncros Hixon iC CarbonSize S & M 15mm rise / Size L & XL 25mm riseback sweep 8° / 780mmSyncros Endurance lock-on grips
ReggisellaSyncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mmS size 140mm / M size 180mm / L & XL size 210mm
SellaSyncros Tofino SL Regular 1.0Carbon rails
Serie sterzoSyncros – Acros Angle adjust & Cable Routing HS SystemStainless / +-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB
ALTRO
RuoteSyncros Revelstoke 1.0S-30 CLF: 15x110mmR: 12x148mm30mm Tubeless ready Carbon rim 28HDT Swiss 240 Ratchet EXP 36 / XD DriverSRAM TyreWiz / Syncros Axle w/Removable Leverwith 6mm AllenT30 and T25 Tools
Gomma anterioreMaxxis Dissector / 2.6″ / 60TPI FoldableTubeless Ready / EXO 3C maxx Terra
Gomma posterioreMaxxis Dissector / 2.6″ / 60TPI FoldableTubeless Ready / EXO 3C maxx Terra
ExtraSRAM AXS Extension CordSRAM TyreWizSyncros Fork Fender
Peso in kg (approx.)17.9 (tubeless / without range extender)
